                                                         Below:
                                                         The drill head travels
                                                         along the length of the
                                                         frame and has a drill
                                                         rod attached.










                                                                                   Above:
                                                                                   Each track frame can be adjusted to change the
                                                                                   angle of the chassis and this works well, while
                                                                                   remaining stiff.





             individual  linked  tracks  that  are  and  piston  are  both  made
             tensioned nicely with a pair of rotating  from metal so there is no natural
             upper rollers giving the tracks a slight  resistance.
             bow. Each track frame is separately     The drilling head is mounted
             connected to the main chassis, with  to a sled which moves along the
             functional  hydraulics  allowing  the  frame and is complemented with
             chassis angle to be adjusted, ideal for  hydraulic lines and a drill rod.
             uneven ground. The control module  As the drill head is lowered, the  Above:
             stands  out,  complete  with  different  hydraulic  bundle  unfolds  and  The control panel has been authentically finished
                                                                                   with three groups of levers and several display
             screens and a whole host of control  this works well while the surface  screens.
             levers split into three groups with the  detailing  of  the  drill  head  is
             console  mounted  to  a  frame  which  sufficient. Another small screw
             allows  both  swivelling  and  height  allows the drill sled to be locked
             movement,  complete  with  a  very  in place and the model can be
             small  hydraulic  ram  for  the  parallel  positioned   in   a   number
             mounting frame.              of  drilling  situations,  even
                The  main  drill  frame  can  be  horizontal.  While  the  Klemm
             adjusted  in  a  multitude  of  different  KR806-3GS may not be model
             positions,  with  no  fewer  than  eight  for  everyone,  there  is  no
             fully  functional  hydraulic  cylinders  denying   that   a   lot   of
             to  change  the  angle,  height  and  development  work  has  gone
             inclination  of  the  frame  which  itself  into creating a very interesting  Above:
             has   several   more   hydraulic  release with the paint finish up    The kinematics of the arm are what impresses most
                                                                                   on the model, with 8 cylinders combining perfectly.
             components that allow the frame to  to NZG’s very high standards.
             traverse the mounting point while also  Even  the  printing  look  good,
             moving the upper of the assemblies at  particularly the markings on the
             the bottom of the frame. A screw is  track frames.
             strategically placed to keep the frame
             in place at the chosen extension and
             this is a nice touch, as the cylinder


                           Below:
        The kinematics of the arm allow drilling
             towards the side of the chassis.
                                                                                   Above:
                                                                                   The drill head has surface detailing and flexible hy-
                                                                                   draulic lines attached, complete with a locking
                                                                                   screw.









                                                                                     Summer 2020 - TPMMW Magazine  13
