Manufacturer: USK Scalemodels Scale: 1:50th Price: £80.00

Bell B60E

Articulated Dump Truck

Above:
The flagship Bell B60E has been
convincingly replicated in 1:50th
scale by USK Scalemodels.

Two axle articulated dump trucks are typically found on building sites with
capacities up to 10 ton and while there have been larger 2-axle trucks offered from

manufacturers like Volvo, in wasn’t until the introduction of the Bell B60E that the
2-axle articulated dumper for quarrying and mining operations became a reality.
Combining the front of a typical ADT with the rear of a typical rigid haul truck, the
combination is certainly interesting, powered by a Mercedes Benz OM473LA
6-cylinder diesel engine delivering a gross output of 577hp. The Alison 7 forward,
1 reverse fully automatic planetary transmission and Kessler transfer case provide
the hauler with a maximum speed of 32mph.

U SK Scalemodels produced demonstrate servicing. The articulating

a 1:50th scale model
chassis has hinted at front drive
of the smaller B30E ADT
has been modelled from the
several years back and it is detailing while to the rear, a driveshaft
great to see them release the articulation joint to the rear axle. The Right:
The dump body achieves a
flagship B60E in 1:50th scale, rear axle suspension struts have been good tip angle with 2-stage
packing some interesting features like replicated but are static, so there is hydraulic cylinders.
the opening bonnet that reveals the no suspension movement and the
internal engine block while the hydraulic steering cylinders operate a
cabin can be tilted to the side to modest range of steering.
