                                                                                   Above:
                                                                                   The main winches for the jib and hook are
                                                                                   integrated into the base structure.








                        that runs on the side of the deck for  top. The simple hook is then used with
                        the  cabin  which  can  be  height-ad-  a  short  tip  extension  (when  in  tip
                        justed using a winch. The large glass  mode).  When  used  in  conjunction
                        surface is easy to see and so are the  with a trolley, the tip is bolted on and
                        three window wipers. The ballast must  then the crane can work with trolley  Above:
                        be attached to the rear of the upper  and hook. The hook descends very  Additional counterweight segments need
                        chassis.  The  basic  element  is  inte-  smoothly and the trolley moves along  to be added.
                        grated into the upper chassis and it is  the whole length of the outrigger arm.
                        possible to attach additional ballast el-  The  outrigger’s  guying  is  modeled
                        ements which would bring it up to 6.0  prototypically  correctly  both  at  the
                        t of weight. Two smaller elements of  front with telescoping bars with thin
                        1.5 t each are attached at the side.  steel cables and at the rear where the
                        The  way  the  extremely  complex  guying is made from white metal. As
                        kinematic of the outrigger arm made  per usual at WSI, the lettering of the
                        up  from  four  segments  which  fold  whole  model  is  very  convincing.
                        down very compactly during travelling  Safety decals on the vehicle, upper
                        is   very   impressive.   Especially  carriage,  ballast  and  even  on  the
                        noticeable is the low weight of the out-  cabin  are  there.  We  were  very
                        rigger arm because of the aluminum  pleased to note that WSI now uses a  Above:
                        casting used, therefore, the model is  completely  twist-free  cable  which  The rear platform can be used for storage.
                        very stable, especially side to side.  descends  through  the  smoothly-run-
                        The  winch  keeps  the  outrigger  arm  ning dolly wheels very easily. The very
                        secure and so the model reaches an  detailed  instructions  guide  the
                        impressive height of 1.87 m at the roll  assembler throughout the process with
                                                    no problems but it is recommended to
                                                    ask a second person for help because
                                                    of the very complex assembly of the
                                                    outrigger arm.
                                                                                         Above:
                                                                                    The crane cabin
                                                                                      runs on a rail,
                                                                                      traversing up
                                                                                     and down the
                                                                                    telescopic mast.



                                                              Left:
                                                              The cabin is fully
                                                              finished and the
                                                              engine compartment
                                                              is finished with
                                                              photo-etch parts.
