Left:
The 45-tonne capacity Belaz 7547
haul truck in 1:50th scale is a good
representation of the original.

BELAZ Below:

Underside structural
support detailing of
the dump body looks
7547 good.

Haul Truck

The smallest BELAZ haul truck to be

modelled in 1:50th scale so far is the
45-tonne capacity 7547 which has plenty
of detail, while also having a high metal
content which gives it a very refined feel
when examining it.

Above: Above: Above:
The single occupancy cabin has a simple but The rear axle oscillates with fitted springs while the The simple lines of the front grill are encapsulated
effective interior, finished with black window trim. wheel hubs have some fine engraving detail for between the access ladders on each side of
the fixing bolts. the engine bay.
