Below:
With the hydraulic cylinder
mounted to the back of the main
boom, the boom certainly looks
different to the regular appearance.

Above:
The model uses the same tooling for the
undercarriage, body and cabin as the
monoboom version of the R922.

Above:
The hydraulic lines have been fully replicated,
using plastic for the fixed lines and flexible
plastic for the hoses.

Above:
Fully extended, the boom
has a low height envelope.

Above:
Below:
The boom can tuck up in length to The quick coupler uses a pin to connect the
form a compact form for transport. bucket, and is compatible with other attachments
produced by Conrad that have been released
with other Liebherr models.

Above:
All the hydraulic cylinders have raised hydraulic
lines and have an authentic range of movement.
