                       at any chosen extension by tightening  in  the  boom  head  are  all  freely
                       the grub screws and this works well,  rotating and two hooks are included
                       allowing any angle to be set.  in the box to offer a choice of light or
                          The SSL frame is another interesting  heavy lifting. The crane cabin is fitted
                       part of the model which has been fully  to  an  arm  which  rotates  from  the
                       replicated, right down to the brackets  storage position into place alongside
                       on the sides of the boom to hold the  the upper body with the mechanism
                       pendent  lines.  Assembly  of  the  having height adjustment for the cabin
                       different connections is by using two  to clear the outriggers when slewing
                       different lengths of bolt and nuts with  and angular adjustment to give the
                       two tools included to make this job  operator a better view when working
                       easy  to  perform.  The  SSL  has  two  at height.
                       winches which need to be reeved up     Access to the main winch is cleverly
                       to the brackets that connect with the  hidden behind the side panel which
                       boom tip and even here, this is very  uses two small magnets to remain in
                       simple to achieve, with small storage  position  when  not  needed  and  the
                       bars included, just like the real crane  winding  key  insertion  releases  the
                       for when the SSL is not required.  winch drum so that the rope can be
                          Each  section  of  the  telescopic  wound out or in. A pair of metal safety
                       boom can be set at 45%, 90% and  railings fit on top of the upper structure
                       100%  extension  with  an  internal  and there is a plastic ladder included
                       sprung bracket locking into place as  which can be hung on the storage
                       it passes over each location to prevent  brackets fitted to the boom. To finish
                       it from sliding back down. The pulleys  off the setup, a metal plate load is  Above:
                                                                                   The crane cabin is mounted to an arm which
                                                    included,  complete  with  Demag  swings into position, with both height and angular
                                                    branding to keep the rope taut so that  adjustment.
                                                    it easily raises and lowers when the
                                                    winch is operated.
                                                       It  is  obvious  that  the  model  has
                                                    been very carefully planned and the
                                                    execution is spot on, so for me, I am
                                                    happy that they took the additional
                                                    time to ensure that the resulting model
                                                    is the best it can be, rather than cutting
                                                    corners to get the model out sooner.
                                                    Rumour has it that IMC are working
                                                    on another large crane project and if
                                                    the Demag AC700-9 is anything to  Above:
                                                    go on, it should be a very welcome  The SSL frame before being fitted to the boom.
                                                    release once it is finished.











                                                           Left:
                                                           It was certainly worth the
                                                           wait, and IMC should be  Above:
                                                           congratulated for a rather  The transport frames are a very welcome addition
                                                           impressive release.     in the “Collector’s Edition” version of the model.
