Manufacturer: Motorart        Scale: 1:32nd        Price: £TBA
     Dimensions: L:191mm, W:58mm, H:83mm        Weight: 740g



                                      Maeda MC815C




                                      Spider Crane























                              Above:
                              Another heavyweight
                              model release from Conrad
                              in 1:50th scale.




                         Above:
             In its transport configuration,
                 the model is compact.




        When it comes to mini-cranes, also referred to as spider cranes for their ability to work in confined spaces
        where standard cranes cannot be deployed, there are not many examples in model form so it was
        refreshing to see a model of the Maeda MC815C tracked spider crane appear at the Bauma. With a
        lifting capacity of 8 ton and maximum working radius of 18.8 metres, the MC815 C has impressive specs,
       with a max lifting height of 19.6 m increasing to 25.5 m with fly jib. Power comes from a Yanmar

       4TNV88C-NMB 2.1 litre diesel engine and the hydraulic motor drive with stepless speed changer
       traverses the vehicle up to 3.2km/h in either direction.

       T     he replica has been modelled
             in  1:32nd  scale  and  while
             this is not the typical scale for
             construction  equipment,  you
        would be forgiven for thinking that it                                  Below:
        is a small machine, so would make a                                     While the model is presented in 1:32nd
                                                                                scale, being at the larger end of the
        better impression in a larger scale. In                                 product offering results in an impressive
        reality,  the  model  is  actually  quite                               and large replica.
        large, and considerably heavy which
        shows  that  the  main  castings  are
        produced in metal. Each of the four
        outriggers swing out from their travel
        position before hydraulic rams angle
        them  downward.  Each  leg  is
        telescopic, extending smoothly with a
        pivoting  pad.  While  the  hydraulics
