                                                                Below:
                                                                Both front and rear
                                                                hydraulics are stiff enough
                                                                to display the model
                                                                raised off its tracks.














                                                                                   Above:
                                                                                   The access ladder rotates authentically from the
                                                                                   stored to lowered position.








                                                       The blade has both height and tilt
                                                    adjustment  with  a  fairly  authentic
                                                    range of movement which is stiff in
                                                    operation, holding any chosen pose.
                                                    The  upper  guard  on  the  blade  is
                                                    perforated which looks much better  Above:
                                                    than the earlier Cat dozer models and  The blade has a nicely engineered perforated
                                                                                   upper spill guard.
                                                    the  cylinders  are  fitted  with  flexible
                                                    hydraulic hoses, as are the cylinders
                                                    at the rear that operate the three-shank
                                                    ripper which can be adjusted in both
               Above: There is plenty of detail on the model, including
               a full safety package and fire suppressant gear.  depth  and  angle  although  due  to
                                                    engineering  decisions  to  prevent
                                                    the pistons from popping out of the
                       captured  which  include  the  access  cylinders, when the frame is raised,
                       ladder that can be rotated through 90  there is no angular adjustment. The
                       degrees from its stowed to lowered  tracks are nicely tensioned to allow
                       position.  Metal  safety  railings  them to run smoothly with the lower
                       and grab rails have been fitted with  roller  detailing  integrated  into  the  Above:
                       service  platforms  having  a  nice  main  track  frame  castings  and  The grey coloured interior of the cabin has been
                       textured surface, not forgetting the fire  the upper drive sprockets have nice  neatly finished, complete with display screen
                       suppression cannisters to the rear.  detailing of the final drive casings.  and controls.















                                                                                   Above:
                                                                                   The panels on each side of the engine bay open
                                                                                   to reveal the innards.







                   Above:
            The ROPS frame and
        cabin roof can be removed
        to fit the supplied operator.
                                                                                     Summer 2020 - TPMMW Magazine  55
