Manufacturer: Ros Scale: 1:50th Price: €201.10
Dimensions: L:397mm, W:1132mm, H:600mm Weight: 2610g

Sennebogen

6140E HD

Duty Cycle Crane

The Sennebogen 6140E HD duty cycle crane
is a versatile machine that can be configured
for a number of different tasks, from lifting,
with a maximum lift capacity of 140 ton and
Right: material handling duties with clamshell or
The dragline bucket
version of the 6140E orange peel grabs to foundation work using
HD is impressive
in size. casing, drill grabs and diaphragm wall
grabs or dragline operations with
drag buckets up to 5.4 cubic metres

capacity.

I talian model producer Ros

has produced three different
configurations
the
of
6140E,
Sennebogen
one
equipped with a drag bucket, one
with a clamshell and the third fitted
with a mechanical diaphragm wall
grab. All three versions use the same
castings for the main machine and
boom setup with the differences
limited to the equipment. The track
frames of the undercarriage are
extendable to increase stability and
they remain fairly rigid at full
extension. There are 4 self-assembly
jacks incorporated into the
undercarriage frame and these can
be lowered.

The upper structure has been
implemented well, with walkways
running along both sides of the
chassis, and additional walkways
with all-metal safety railings found on
the upper area. Access ladders are
