Below:
The screening unit connects
to the main conveyor and
can be used to return
oversize material.

Above:
The hopper sides are rear can be lowered to
reduce height for transport.

beneath the hopper is a guide to fit The design of the screen includes
the natural fines conveyor which can the ability to transport it using a
be installed on either side. hookloader truck and this has been
The oversize return conveyor somewhat implemented on the model
can be used in two modes, either to with the lifting bracket integrated into
stockpile the oversize material or to the frame. Unfortunately, the end of
return it to the hopper, and this is the hopper does not fold as it does on Above:
implemented with the ability to rotate the full-sized screen so sticks out from The oversize return conveyor sits snugly along the
side of the chassis and can fold to reduce height.
the conveyor frame which has a the back of the truck a little too far. The
hinged upper section, again matching heart of the crusher is the impact
the real machine to reduce transport chamber and this has a hinged upper
height. The discharge conveyor is cover which can be lifted a little with
fitted with a magnetic separator which flexible rubber strips fitted over the
can be adjusted to move it closer opening to prevent material being
to the rubber belt. The included thrown out. Conrad has done a great
screening deck is integrated with job in implementing the MR 130 Z
another conveyor to stockpile the final EVO which is finished in the latest
product and this can be connected if Wirtgen Group markings and
required. decoration.
Above:
The main discharge conveyor is completed with
a magnetic separator which is adjustable.

Above:
The opening to the impact chamber is hinged
and can be raised a little.

Above:
The detachable screening unit can
be transported on a hookloader
truck which is a nice feature.
